Working Temperature | Working power | Power | Weight | Size |
-20℃—85℃ | DC 5V or DC 12-24V input | 5W | 0.8Kg | L215mm * W146 mm* H30 mm |
00: UCS19**, UCS29**, TM18*, SM167**, WS28**, GS82**, SK6812 (maximum with light 1024*4=4096 pixels, recommended loading ≤512*4=2048 pixels)
01: SM16716, 16726 (maximum with light 1024*4=4096 pixels, recommended loading ≤512*4=2048 pixels)
02: P9813 (maximum with light 1024*4=4096 pixels, recommended loading ≤512*4=2048 pixels)
03: LPD6803 (maximum with light 1024*4=4096 pixels, recommended loading ≤512*4=2048 pixels)
04: LX1003, 1203 (maximum with light 1024*4=4096 pixels, recommended loading ≤512*4=2048 pixels)
05: WS2801 (maximum with light 1024*4=4096 pixels, recommended loading ≤512*4=2048 pixels)
06: LPD1886 (maximum with light 1024*4=4096 pixels, recommended loading ≤512*4=2048 pixels)
07: TM1913 (maximum with light 1024*4=4096 pixels, recommended loading ≤512*4=2048 pixels)
08: TM1914 (maximum with light 1024*4=4096 pixels, recommended loading ≤512*4=2048 pixels)
09: P9883, P9823 (maximum with light 1024*4=4096 pixels, recommended loading ≤512*4=2048 pixels)
10: DMX (maximum with light 512*4=2048 pixels, it is recommended to load ≤320*4=1280 pixels)
11: DMX 500K (maximum with light 512*4=2048 pixels, it is recommended to load ≤320*4=1280 pixels)
12: DMX 250K-CZF (maximum with light 512*4=2048 pixels, recommended loading ≤320*4=1280 pixels)
13: DMX 500K-CZF (maximum with light 512*4=2048 pixels, recommended loading ≤320*4=1280 pixels)
14: UCS5603-Test (maximum with light 1024*4=4096 pixels, recommended loading ≤512*4=2048 pixels)
15: UCS5603A (maximum with light 1024*4=4096 pixels, recommended loading ≤512*4=2048 pixels)
16: UCS5603B (maximum with light 1024*4=4096 pixels, recommended loading ≤512*4=2048 pixels)
17: TM1814 (maximum with light 1024*4=4096 pixels, recommended loading ≤512*4=2048 pixels)
18: INK1003 (maximum with light 1024*4=4096 pixels, recommended loading ≤512*4=2048 pixels)
19: APA102 (maximum with light 1024*4=4096 pixels, recommended loading ≤512*4=2048 pixels)
20: UCS8904 (maximum with light 1024*4=4096 pixels, recommended loading ≤512*4=2048 pixels)
21: SM16714 (maximum with light 1024*4=4096 pixels, recommended loading ≤512*4=2048 pixels)
22: SM16813 (maximum with light 1024*4=4096 pixels, recommended loading ≤512*4=2048 pixels)
23: GS8512 (maximum with light 512*4=2048 pixels, recommended loading ≤320 *4=1280 pixels)
