DC24V Playground 60mm Punching Hole 18 Leds Cabochon Led Rgb Pixel Amusement Light

  • Product model: YJLED-076-SV18RGB-DMX-D24V
  • LED type: 5050smd
  • Input voltage: AC24V
  • Lamp power: 3W
  • IP rating: IP65
  • Control mode: Controller control change
  • Luminous color (color temperature): RGB change color
  • Warranty: 1
  • LED chip brand: Sanan
  • Luminous angle: 240°

DC24V Playground 60mm Punching Hole 18 Leds Cabochon Led Rgb Pixel Amusement Light


Product Parameters

rgb cabochon lights

Model NoYJLED-076-SV18RGB
Power3W/M
Lighting Source18pcs SMD5050 RGB LED
Input VoltageDC24V
Power Factor 0.9
Chip5050 SMD
CRI75
Color RGB
Beam Angle240°
RGBprogramme
IP DegreeIP65
LED quantity18pcs
Working Temperature-25℃-+45℃




Product Description:


The Cabochon Led Rgb Pixel Amusement Light are the perfect addition to your amusement ride, Ferris wheel, or fairground setup. These lights, with a diameter of 60mm, are built with 18pcs of high brightness SMD5050 RGB LEDs, ensuring a stunning and vibrant illumination. Designed with a round transparent shell, these lights offer a 360-degree lighting effect.

Features:

High Brightness LEDs: The Cabochon DMX512 Pixel LED Lights are equipped with 18pcs of SMD5050 RGB high brightness LEDs. These LEDs deliver a brilliant and eye-catching illumination that will attract attention from every angle.

Addressable RGB Pixel LED: These lights are fully addressable, allowing you to control each individual LED. They can be easily operated with an SD card controller, DMX ArtNet controller, or any other device that can operate with SPI signal lights.

Wide Compatibility: The Cabochon DMX512 Pixel LED Lights can be used with DMX decoders or DMX controllers that have multi-function capabilities with DMX to SPI conversion. This ensures seamless integration and control of the LED lights.

Applications:

amusement cabochon lights-YJLED-076.jpg




Caution:

Please read the specification before used:

working temperature range -25°C-45°C

working voltage range less than +_10

Please turn off the power before installation


How cabochon lamp led pixel light Works:

The Cabochon LED Pixel Lights are designed to be easily installed and controlled. Simply connect the lights to the appropriate power source and connect the control signal to your desired controller. Whether you choose to use an SD card controller, DMX ArtNet controller, or any other compatible device, you'll be able to create stunning lighting effects with ease.

FAQ:

Q: How many LEDs are included in each Cabochon? A: Each Cabochon DMX512 Pixel LED Light contains 18 high brightness SMD5050 RGB LEDs.

Q: What is the input voltage required for these LED lights? A: These LED lights require a DC24V power supply.

Q: Can I control these lights with a DMX controller? A: Yes, these lights are compatible with DMX512 controllers. However, it's important to note that you may need to use DMX decoders or a DMX controller with DMX to SPI conversion capabilities.

Enhance your amusement rides, Ferris wheels, and fairground attractions with the captivating Cabochon DMX512 Pixel LED Lights. Create mesmerizing lighting effects and captivate your audience with these high-quality, addressable RGB LED lights. Order now and take your displays to the next level!

Cabochon Led Rgb Pixel Amusement Light is widely used in Ferris Wheel Fairground led lights,Advertisement Outdoor Signboard Backlight,Stage Decoration Light,Stage Decoration Light,Kids Rides Decoration.Aglare is a professional LED amusement lighting Manufacturers, Factory ,Suppliers From China.

We can offer led rgb pixel amusement light,pixel led fairground light,cabochon lamps,cabochon pixel led light,cabochon ride light,smd 5050 rgb pixel light,rgb pixel light, led pixel programmable light, etc.Let's take a look at them.
